Cable RFI / EMI Suppression Cores
Split into two halves for easy application to existing cables.
AL (nH/Square Turn or nH/N2) is the AL value. L is inductance in nH (nanohenries)
N is the number of turns of a wire
Required turns (N) = square root of (desired 'L' /'AL'), √'L' /'AL', or 1000 turns=, (square rooted)
O.D. is the outer diameter of the core
I.D. is the inside diameter of the core
HT is the height of the core
LH is the length of the core
Hole type is the number of holes in ferrite core. Some may have multiple holes
CWS ByteMark Part Number is the part number to use to place purchase order. 1 inch = 25.4 mm
Color may vary by material and coating characteristics
•Technical Data and Specifications
•www.bytemark.com
Low order fees are charged to total a minimum payment of $25.
Quantity marked in red is subject to availability and prior sales, or back order.
Orders are processed in 2 to 3 business days.
Please call for volume and price inquiries or email sales@cwsbytemark.com
Displaying 1 to 5 (of 5 Products)
| Product Image | Part Number | Material | Description | Impedance @ 25 Mhz |
Impedance @ 100 Mhz |
Dimensions O.D/W x [I.D.] x LH x [HT] x (gap)(in.) | weight (g) | Qty. | Price |
|---|---|---|---|---|---|---|---|---|---|
S-251-43-2P  |
43 | Round Split Core with Case |
110 ohms Min |
225 ohms +/- 20% |
0.870 x [0.260] x 1.272 | 31.00 | 1222 | $3.75 Buy Now |
|
| S-351-43-2P |
43 | Round Split Core with Case | 110 ohms Min |
225 ohms +/- 20% |
0.870 x [0.400] x 1.272 | 42.00 | 3 | $3.75 Buy Now |
|
| S-3851-43 |
43 | Flat Cable Core No Case |
76 ohms Min. |
195 ohms +/- 20% |
1.500 x [1.050] x 1.000 x [0.475] x (0.075) | 51.00 | 10 | $5.00 Buy Now |
|
| S-551-43 |
43 | Solid Flat Cable Core No Case |
76 ohms Min. |
195 ohms +/- 20% |
1.775 x [1.355] x 1.125 x [0.490] x (0.060) | 71.00 | 80 | $3.75 Buy Now |
|
| S-951-43-2P |
43 | Flat Cable Core with Case |
70 ohms Min. |
225 ohms +/- 20% |
2.670 x [2.050] x [1.272] x 0.320 | 110.00 | 36 | $10.00 Buy Now |
